Mechanical Data; General Data - bürkert 8045 Schnellstartanleitung

type of fluid
Fluid group 2 par. 1.3.a
Fluid group 1 par. 1.3.b
Fluid group 2 par. 1.3.b
6.3.

mechanical data

material (8045 with
part
flow sensor in pVdf)
Housing / seal PC / NBR
Cover with lid / PC / silicone
seal
Front foil
M20x1,5 cable
glands / seal
Screws
Nut PC
Flow sensor PVDF
(exposed to the
fluid)
8
conditions
DN ≤ 32
or DN > 32 and PNxDN ≤ 1000
PNxDN ≤ 2000
DN ≤ 200
or PN ≤ 10
or PNxDN ≤ 5000
material (8045
with flow sensor in
stainless steel)
Black PPA / NBR
PSU / silicone
Polyester
PA / neoprene
Stainless steel
PPA
Stainless steel 316L
(DIN 1.4404)
English
Type 8045
Technical data
material (8045 with
part
flow sensor in pVdf)
Seal FKM
Earth ring of the Stainless steel 316L
flow sensor (DIN 1.4404) or Alloy
C22
Electrodes holder -
Electrodes Stainless steel 316L (DIN 1.4404) or Alloy
6.4.

General data

Min. fluid conductivity 20 µS/cm
Fluid temperature The fluid temperature may be
restricted by the fluid pressure, the
material the flow sensor is made of
and the material the S020 fitting used
is made of.
• 8045 with flow sensor • 0 to +80 °C
in PVDF
• 8045 with flow sensor in • -15 to +110 °C
stainless steel
material (8045
with flow sensor in
stainless steel)
8045 with a G2" nut:
FKM
-
PEEK
C22
