Installation and wiring
A
Position the
switch to the left.
+
-
4-20mA input at external
device
I
A
CURRENT
Iout L+ L - PE P+ P-
SINK SOURCE
Supply
AO1
18...36 Vdc
Fig. 18: Wiring of the 4-20 mA output (AO1) in sinking mode
*) If a direct earth connection is not possible, fit a 100 nF/50 V
capacitor between the negative power supply terminal and the earth
Type 8045
18-36 V DC
300 mA
+
-
(*)
Power supply
PULSE
DO1
PE
7.5.5. Wiring the Do1 transistor output
18-36 V DC
300 mA
+
-
Power supply
(*)
Iout L+ L - PE P+ P-
Supply
AO1
18...36 Vdc
Fig. 19: NPN wiring of the DO1 transistor output
*) If a direct earth connection is not possible, fit a 100 nF/50 V
capacitor between the negative power supply terminal and the earth
English
+
5-36 VDC
-
+
-
PLC
PULSE
DO1
PE
