bürkert 8045 Schnellstartanleitung Seite 18

Power cable shield
If a direct earth connection is not possible, fit a 100 nF / 50 V
1)
capacitor between the negative power supply terminal and the
earth.
Fig. 11: Equipotentiality skeleton diagram with pipes in metal
18
Power supply
18-36VDC
+
-
1)
Metal pipe
English
Type 8045
Installation and wiring
7.5.2. Terminal assignment and use of the
selectors
A
CURRENT
SINK SOURCE
4 pin ribbon ca-
B
ble coming from
OFF ON
the flow sensor
4
DO3
5
Selector A : see Fig. 13
Selector B : see Fig. 14
1
Iout L+ L - PE P+ P-
Supply PULSE
AO1
18...36 Vdc DO1
PE
DI1
PE
-
+
DO2
2
3
