8.3. Description of the navigation keys and the state leDs
• Scrolling up the
parameters
• Incrementing the figure
selected
Device state LED: see fol-
lowing table.
26
English
Type 8045
Adjustment, commissioning
• Selecting the displayed parameter
• Confirming the settings
Status LED of relay DO3 (LED ON =
contact closed)
Status LED of relay DO2 (LED ON =
contact closed)
• Reading the messages
• Scrolling through the parameters
• Selecting the figure on the left
