DUS 60 Bedienungsanleitung Digitales Ultraschalldiagnosesystem
3. Sonstige Messungen:
Abk. Beschreibung
AOD Aortic root Diameter
( Aortendurchmesser)
LAD Left Atrium Diameter
( Linksatrialer Durchmesser )
CA Cardiac cycle apex A
CE Cardiac cycle apex E
EF SLP Ejection Fraction Slope (Slope
Ejektionsfraktion)
ACV AC Decreasing Velocity
DEV Deceleration Velocity
DCT Deceleration Time
MAVO1 Aortic Valve Volume Opened,
beginning
MAVO2 Aortic Valve Volume Opened,
ending
AA Aortic Amplitude
LVMW Left Ventricular Muscle Weight
LVMWI Aortic Valve Stroke Volume
CA/CE Verhältnis CA/CE
LAD/AO Left Atrium Diameter / Aortic root
D Diameter (LAD/AOD)
AVSV Aortic Valve Stoma Valve flow
QMV Mitral valve instantaneous flow
rate
Methode
Distanz (mm)
Slope (mm/s)
Zeit (ms oder s)
Distanz (mm)
LVMW (g) =1.04* ({IVSTd (cm)+LVIDd (cm)+LVPWd
3
(cm)} -LVIDd
LVMWI (Keine Einheit) = LVMW/KOF
CA/CE (Keine Einheit) = CA (mm)/CE (mm)
LAD/AOD (Keine Einheit) = LAD (mm) / AOD (mm)
AVSV (mL) = MAVO1 (cm)+MAVO2 (cm)*
ET (s)*50+AA (cm)
QMV (mL) = 4*DEV (cm/s)*DCT (s)
Tabelle 8-3 Sonstige Messungen
- 115 -
3 3
(cm) )-13.6
