2

Technical data

The following information are the dimensions and indications of weight and the manufacturer's
approved machine data.
2.1

Electrical connection

Connection
2.2

Machine data

Spindle speeds [min
Spindle taper
Spindle hole, rod opening [mm]
Bed width [mm]
Travel of top slide [mm]
Travel of cross slide [mm]
Tailstock cone
Tailstock sleeve travel [mm]
Longitudinal feed [mm/rev]
Pitch - Metric [mm/rev]
Pitch - inch [threads/inch]
2.3

Working area

Height [mm]
Length [mm]
Depth [mm]
GB TU2506 | TU2506V | TU2807 | TU2807V
Page 94
230V 750 W ~ 50 Hz
400V 750 W ~ 50 Hz
230V 1.5 kW ~ 50 Hz
TU2506
125 - 2000
-1
]
TU2506V
30 - 4000
0.2 0.3 0.4 0.5 0.6 0.62 0.75 0.8 0.88 1.0 1.2
8 9 9.5 10 11 12 14 16 18 19 20 22 24 28 36
TU2506
TU2506V
Original operating instructions
TU2506
230V 850 W ~ 50 Hz
or
400V 850 W ~ 50 Hz
TU2506V
230V 1.5 kW ~ 50 Hz
MT4
26
135
70
110
MK2
65
0.07 0.10 0.14 0.20 0.28 0.4
1.25 1.5 1.75 2.0 2.5 3.0 3.5
38 40 44 58 56
2000
2200
1900
TU2807
TU2807V
TU2807
150 - 2000
TU2807V
30 - 4000
180
60
160
85
TU2807
TU2807V
2000
2200
1900
Technical data
Version 1.0.1 2014-05-16
