Appendix

6.1

Copyright

This document is copyright. All derived rights are also reserved, especially those of translation,
re-printing, use of figures, broadcast, reproduction by photo-mechanical or similar means and
recording in data processing systems, neither partial nor total.
Subject to technical changes without notice.
6.2

Terminology/Glossary

Term
Spindle stock
Lead- screw nut
Lathe chuck
Drill chuck
Lathe saddle
Cross slide
Top slide
Taper mandrel
Tool
Workpiece
Tailstock
Rest
Lathe dog
6.3

Change information operating manual

Chapter
4.10
CE
GB TU2506 | TU2506V | TU2807 | TU2807V
Page 150
Explanation
Housing for the feed gear and the synchronous belt pulleys.
Split nut which engages the lead screw.
Clamping tool for holding the workpiece.
Drill bit chuck
Slide on the slideway of the machine bed which feeds parallel to the tool axis.
Slide on the lathe saddle which moves transversely to the tool axis.
Swivelling slide on the cross slide.
Taper of the bid, the drill chuck or the center.
Cutting tool, bit, etc.
Piece to be turned or machined.
Movable turning aid.
Follow or steady support for turning long workpieces.
Device or clamping aid for driving pieces to be turned between centers.
Short note
Feed, mechanical end stops
Updated standards CE Declaration
Original operating instructions
new version number
1.0.1
1.0.2
Appendix
Version 1.0.1 2014-05-16
