MICRO-EPSILON IF1032/ETH Betriebsanleitung Seite 71

Anhang | EtherCAT-Dokumentation
Objekt 2060h: Controller Settings
2060
Subindizes
0
1
2
3
4
Objekt 2100h: Controller Interface
2100
Subindizes
0
1
3
4
5
6
7
IF1032/ETH
RECORD Controller Settings
VAR Anzahl Einträge
VAR Samplerate
VAR Averaging type
VAR Averaging number
VAR Trigger
RECORD Controller Interface
VAR Anzahl Einträge
VAR Ethernet/EtherCAT
VAR Ethernet Address type
VAR Ethernet IPAddress
VAR Ethernet Subnet
VAR Ethernet Gateway
VAR Ethernet Dataport
4 Unsigned8
2083,3 Hz Float
Off Enum
2 Unsigned32
Off Enum
7 Unsigned8
EtherCAT Enum
Static Enum
169.254.168.150 Visible String
255.255.0.0 Visible String
169.254.168.1 Visible String
10001 Unsigned16
ro
ro
rw
rw
rw
rw
ro
ro
rw
rw
rw
rw
rw
rw
