Mechanics and accessories
Suitable mechanics:
Order No. 4448.LN
Order No. 4449.RXN, 4450.LN
Order No. 4447.M
Order No. 4445, 4446
Recommended main rotor blades:
(to suit mechanics installed)
Decal sheets
Order No. 4452.97: fluorescent red, green, yellow
Order No. 4452.98: dark blue, blue, light blue
Order No. 4452.99: dark red, red, light red
Adhesives
UHU plus schnellfest, Order No. 962, fast-setting
UHU plus endfest 300, Order No. 950, slow-setting, for gluing GRP to wood
UHU Blitz, thin cyano-acrylate, Order No. 5803
Thick cyano-acrylate, Order No. 1101, for tacking parts together
Filler agent, e.g. Order No. 963, for thickening resin
Tools required:
Minimum set: assortment of files (round, half-round, flat), set of twist drills, light tin-snips,
fretsaw, various screwdrivers, allen keys and general-purpose pliers. Coarse abrasive paper,
e.g. 100-grit, Order No. 1068.1, for roughening joint surfaces and for sanding the GRP
mouldings.
Radio control system (see Mechanics manual and main Graupner catalogue)
The model requires a radio control system fitted with special helicopter options, or a micro-
computer radio control system such as the mc-12, mc-14, mc-15, mc-19, mc-22 or mc-24
Servos (high-quality servos must be used), e.g.
C 4421, Order No. 3892
Gyro:
PIEZO 5000 gyro system, Order No. 5146, with NES-8700G super-servo, Order No. 5156, or
PIEZO 550 gyro system, Order No. 5147, or G490T gyro system, Order No. 5137.
Electronic speed governor:
mc-HELI-CONTROL, Order No. 3286
Receiver power supply:
For safety reasons it is essential to use a pack of at least 1800 mAh capacity. We also
recommend a voltage monitor module, Order No. 3138, which allows you to monitor the battery
voltage constantly.
Switch harness: Order No. 3050, suitable receiver battery: Order No. 2568.
(see also Mechanics manual)
UNI-MECHANICS 2000
UNI-EXPERT mechanics
UNI-EXPERT Elektro mechanics
Starlet 50
6
Jet Ranger
