Sl Analytics UviLine Sl 5000 Gebrauchsanleitung Seite 214

216
- Change the name if necessary.
- Confirm with <START ENTER> key.
11.3.6.1.3 Absorption/Transmission, Concentration, Multi-wavelengths mode
<HOME>
Concentration,
Absorbance / % Transmission
Multi-wavelengths
– [Setup] or [General setup] from the main menu
– Measured value memory
- Selection of files to be exported
- <STORE>
- [Location]
- Select «USB memory»
The measurement data of Absorbance/ Transmission, Concentration and multi-wavelengths are stored
in the measurement data memory first, either automatically (see paragraph 12.3.3.2) or manually
(with the <STORE> key, see paragraph 12.3.3.1).
Data stored in the measurement data memory can be filtered with filter criteria
and then exported in the PC readable in "*.csv" format.
- Press F1 key [Setup] inside one of the measuring mode or [General setup] from the main menu
- If necessary, set any filter criteria with [Setup].
- Press <STORE> key to open a save dialog box.
The spectrophotometer automatically suggests the location, Internal DataB folder, and a file name.
- If necessary, use F1 key [Location] to change the location (USB memory).
- If necessary, change the suggested file name.
- Press <START ENTER> to save the selected results.
Data are saved.
11.3.6.2 Copying all files onto a flash drive
All files containing measurement data can be easily transmitted from the spectrophotometer (Internal DataB
folder) to a connected USB memory.
<HOME>
– [General setup]
– Save all data on USB memory
- Set the USB memory in place.
- Press F1 [General setup] key.
- Select « Save all data on USB memory».
- Wait few seconds. It will display:
Memory
