4.2 Keyboard

4.2.1 Overview
1: F1 to F4 function keys (functions which depend on the menu)
2: Fix function keys.
3: Alphanumeric key block.

4.2.2 Keys function

Key
Overview
1
3
Fig. 17 Keyboard
Designation
<ON/OFF>
<HOME>
<PRINT>
<STORE>
<ZERO BLANK>
<TIMER>
<Esc>
<START ENTER
« ▲ » or « ▼ ».
« ◄ »
« ► »
2
Function
Switch the spectrophotometer ON and OFF
Switches to the main menu from any operating situation.
Actions that are not completed are canceled.
Downloads the displayed value to an interface.
Saves a displayed value or spectrum or kinetic curve.
Starts one of the following measurements, depending on
the operating situation:
- Zero adjustment
- Blank value measurement
- Baseline measurement
Open "Timer" menu.
Cancels the running action.
- Entries that have not yet been accepted are discarded.
– Switches to the next higher menu level.
– Starts an action (e.g. measurement)
– Opens a selected menu
– Confirms a selection or entry
Moves the selection in menus and lists one position up
or down.
- Deletes the character left of the cursor during character
entries
- Moves the cursor to the left in a spectrum or
kinetic diagram.
– Moves the cursor to the right in a spectrum or kinetic
diagram.
