NOTE: The functions as « Zoom », « Mark points », « Integral » and « Derivative » are also available for a
derivative curve.
A derivative curve can be also recorded in memory with <STORE> key.
9.7.5.6 Spectra comparison
<HOME>
Spectrum
– [Edit]
- Compare spectrum
Load a second spectrum into the same diagram for direct comparison.
WARNING: The comparisons of spectra can be done only on spectra which do not result from calculations
(derivative, multiplication...)
- Press F4 key [Open] and select the first spectrum
- Press F2 key [Edit].
- Select « Compare spectrum » with « ▲ » and « ▼ » keys. Confirm with <START ENTER> key.
- Select the second spectrum and confirm with <START ENTER> key.
To come back to a normal screen (first selected spectrum):
- Press on F2 key [Edit].
- Select « Original values » with « ▲ » and « ▼ » keys. Confirm with <START ENTER> key.
Spectrum mode 189
