4 Overview

4.1 Overview of the device

4
3
1: Cover of the cell compartment
2: Cell compartment
3: Keyborad
4:.LCD graphic screen
5: Connection for power supply
6: RS232C plug
7: USB-A plug
8: USB-B plug
Overview
Fig. 15 Front of the meter with control elements
5
Fig. 16 Back of the meter with the interfaces
6 7 8
125
1
2
