6. Interface
Command
:atr <1 ... 10000>
EN
:ats <1 ... 10000>
Interface output
:o <0 | 1>
Control mode
:pa <-110 ... 110>
:pd
:pr <-1100 ... 11000>
:ps <-10 ... 110>
:pu
:saz<0 | 1>
:sbr<0 ... 1>
:sbu<0 ... 1>
:sci<n | u | r>
sdb <0 ... 100>
:spu <0 ... 9>
32
Function
Tolerance band
Start delay (phase 2)
Output of status information
via interface
Increase the target pressure
specification by x percent
Target pressure
specification
Adjust the current operating
and measuring ranges
Target pressure
specification in percent
Target pressure
specification
Set auto zero (in Measure
and Control modes)
Set baud rate RS-232
Set USB baud rate
Select active interface
Set communication
interface
Display brightness
Pressure unit
Response
1 ... 10000 --> tolerance in 0.01 % FS
(full scale) of the instrument measuring
range. Once the instrument has been
controlled within this tolerance band for
one second, the hold time expires.
1 ... 10000 --> time in seconds
0 --> Off
1 --> On
-110 ... +110 --> change in target
pressure specification in %
Decrease by currently set step size in
% (Step DOWN).
-1,100 ... +11,000 --> new measuring
range in 0.01 % FS
-10 ... +110 --> target pressure
specification in %
Increase by currently set step size in %
(Step UP)
0 --> Off
1 --> On
0 --> 1200
1 --> 2400
2 --> 4800
3 --> 9600
4 --> 14400
0 --> 1200
1 --> 2400
2 --> 4800
3 --> 9600
4 --> 14400
n --> Interface off
u --> USB active
r --> RS-232 active
0 ... 100 --> brightness in %
0 --> Pa
1 --> hPa
2 --> kPa
3 --> mbar
4 --> bar
5 --> Torr
WIKA operating instructions, model CPC2000
5 --> 19200
6 --> 28800
7 --> 38400
8 --> 56000
9 --> 57600
5 --> 19200
6 --> 28800
7 --> 38400
8 --> 56000
9 --> 57600
6 --> mmHg
7 --> inHg
8 --> psi
9 --> mmH O
2
10 --> inH O
2
