5. Commissioning and operation
3. Confirm with [SELECT].
⇒
For the automatic mode, the submenu items RANGE, UNIT and STEPS are not
relevant.
4. With the [▲] or [▼] buttons, select the menu item SETTINGS.
5. Confirm with [SELECT].
⇒
The submenu item ZERO is not relevant.
6. In the submenu, select the item AUTO-MODE with the [▲] or [▼] buttons.
7. Confirm with [SELECT].
The following items can be set in the AUTOMATIC MODE:
Menu item
RANGE
UNIT
STEPS UP
STEPS DOWN
CONFIGURATION 1
In the submenu item CONFIGURATION 1, further settings can be defined for the
automatic mode.
Settings in the submenu item AUTO-MODE CONFIG 1
Menu item
CYCLES
T START
T STOP
T HOLD
T PAUSE
AUTO ZERO
WIKA operating instructions, model CPC2000
Meaning
Pressure range to be measured
Selection of the pressure unit
Pa hPa
■ ■
kPa bar
■ ■
The number of steps which will be taken to increase the pressure. The
step size is calculated by the instrument itself.
The number of steps which will be taken to decrease the pressure. The
step size is calculated by the instrument itself.
Further required settings for the automatic mode can be set.
AUTO-MODE CONFIG 1
-------------------------
CYCLES
T START
T STOP
T HOLD
T PAUSE
AUTO ZERO
Meaning
Here the number of cycles to be carried out in automatic mode should
be set.
Delay time to vent the sensor
Delay time after reaching the maximum defined pressure
Hold time until a new pressure value is reached
Delay time between two cycles
Automatic zero point correction at the completion of each cycle
mbar inH₂O
■ ■
psi inHg
■ ■
001
00005 s
00005 s
00005 s
00005 s
ON
EN
mmHg
■
Torr
■
