4. Design and function
4. Design and function
4.1 Overview
5
4
Low-pressure controller model CPC2000
1
Function buttons
2
Handle
3
Display
4
Pressure connections
5
4.2 Scope of delivery
Instrument
■
Power supply unit
■
Calibration certificate
■
Ordered accessories
■
Operating instructions
■
Cross-check scope of delivery with delivery note.
4.3 Description
The pressure generation from 1 ... 1,000 mbar is achieved using an integrated, electric
pump, which makes a positive and/or negative pressure available on both the hose
connections.
As soon as the instrument is switched on, a zero point adjustment is automatically
carried out, so that a zero-point drift is eliminated.
The subsequent preparation of a calibration requires only a few settings. First, using
the [MENU] button, select one of the stored pressure units and the variable pressure
change step in the range of 0 ... 50 %.
