5. Commissioning and operation
Usage
On leaving the menu, the zero point of the internal sensor is adjusted, dependent upon
the setting. The instrument then begins to measure the subsequent pressure.
EN
MEAS
6
+00.002
5
Using the [ZERO] button in the measuring mode, the instrument's zero point can be
compensated at any time.
If the connected pressure should exceed the permissible maximum load
(125 %), the internal sensor will be closed off using a solenoid valve.
The display will then show ERROR. Using the [SELECT] button, the
instrument can be opened and unlocked again.
5.6

Automatic mode "AUTO"

In the automatic mode AUTO, a pressure profile can be stored. This is especially useful
when multiple pressure sensors or pressure switches are to be calibrated with identical
values. The mode also enables a defined profile to be carried out several times in
succession.
AUTOMATIC MODE setting
1. Press the [MENU] button.
2. Confirm the menu item MODE with [SELECT] and press the [▲] or [▼] buttons until
AUTO is displayed.
22
1
+10.000 mbar
+ 0% +0.002
4
AUTOMATIC-MODE
-------------------------
RANGE
UNIT
STEPS UP
STEPS DOWN
CONFIGURATION 1
End value
1
Pressure unit
2
2 Measured value
3
Set point in % of full scale
4
3
Battery status
5
Operating mode
6
0...+10.000
mbar
005
005
-->
