Safety
OPERATING INFORMATIONS
Symbol Meaning
The specification of the maximum load limit (WLL) on the type
plate of the suction plate has priority!
Function lever for vacuum and travel mode
Joystick for mast alignment
Limit the swivel range of the articulated boom when working in the
immediate vicinity of roads ("SAFESTOP") - DANGER of
accidents with vehicles
Indication of the maximum payload as a function of counterweight
and throat depth
Lashing eyelet for securing the laying machine to the transport
vehicle by means of chains or tension belts
52220015 / 52220015 -150 / 52220015-200 / 52220015-250 8 / 40
Order-No. Size
48 x 125
29040730
mm
29040478 185x30 mm
29040477 50x50 mm
29041132 100x132 mm
29041094 95x50 mm
29040755 Ø 60 mm
