Operation
4.3 Structure of the boom
Before the diesel engine can be started, the selector switch on the control
unit l must be set to "Manual (HAND)" (and left in this position).
1. To raise the boom arm, start the motor (see chapter "Starting the drive"). (Fig. 1; 1A)
2. Press joystick backward (toward the operator) to raise the boom arm. (Fig. 2; 2A).
3. Alternative: Use automatic mode. When the selector switch is set to "Auto", the boom arm moves upwards
"automatically". (Fig. 3).
It is essential to ensure that no one is in the danger zone. Risk of injury!
To stop the automatic mode, set the selector switch back to "Manual (HAND)"!
Fig. 2
52220015 / 52220015 -150 / 52220015-200 / 52220015-250
Fig. 1
Fig. 2A
20 / 40
Fig. 1A
Fig. 3
