PICTOGRAMS ON THE TP2000
1) R
EAD THE MANUAL
Carefully read the contents of this manual before com‐
missioning, use, maintenance, refuelling or other opera‐
tions on the machine.
Label position: in front of the operator on the distributor
support.
2) M
ACHINE WORKING
Keep outside of the operating range of the moving
machine.
Label position: right‐ and left‐hand side of the lifting gui‐
des.
3) T
RAVELLING DIRECTION
This label indicates the recommended travelling direction,
so that impact with any obstacles to be driven over can be
dampened by the shock absorbers connected to the idler
roller.
Label position: tracked undercarriage chassis.
4) D
ISTRIBUTOR CONTROLS
01)
TABLE
Label position: distributor
guard.
5) S
AFETY DISTANCE
This label warns anyone in the vicinity to be careful and
keep a safe distance from the working machine as the lifted
loads may cause serious harm or damage to people.
Label position: on the lifting guides.
10
A I N T E N A N C E M A N
A I N T E N A N C E M A N
( . 8 ‐
POS TABLE
( . 13 ‐
POS TABLE
( . 5 ‐
POS TABLE
, 2000,
TP
( . 21 ‐ 01)
POS TABLE
U A L
U A L
01)
01)
01)
FIXED UNDERCARRIAGE
AKUU
, (
PETROL ENGINE POS
MUTP2000171893021216
TP2000
. 1 ‐
