Graf one2clean Einbauanleitung Seite 21

7.
Place the upper shell with the baffle on top of the
lower shell. Assemble the clamps for connecting
the upper and lower shells.
9.
2700 L 3750 L
145 mm 145 mm
Drill the inflow and outflow with a DN 110 core drill
(with a diameter of 124 mm).
11.
Slide the outflow pipe through the outflow hole
from the inside.
mail@graf.info
www.graf.info
4. Installation of the set-up kit
H
H
4800 L 6500 L
190 mm 205 mm
21 / 80
Assemble the clamps for connecting the upper and
lower shells.
De-burr the hole. Insert the DN 110 lip seal. In the
case of the outflow, the direction of the feed-
through must be from the inside out. Affix the "Out-
flow" sticker.
Place the suction pipe socket on the airlift pump.
Note the anti-twist protection. Secure the suction
pipe socket with the screw (3.5x6.5).
8.
10.
12.
Anti-Twist
protection
