Graf one2clean Einbauanleitung Seite 15

one2clean and one2cleanXtra installation
one2clean
Item no.
106850 Set-up kit 3 inhabitants
106851 Set-up kit 5 inhabitants
106852 Set-up kit 7 inhabitants
106853 Set-up kit 9 inhabitants
one2cleanXtra
Item no.
106413 Set-up kit 3 inhabitants
106414 Set-up kit 5 inhabitants
106415 Set-up kit 7 inhabitants
106416 Set-up kit 9 inhabitants
It is essential that you observe the
points described in these instruc-
tions. Failure to do so will invali-
date all warranty claims. For all ad-
ditional items ordered from GRAF,
separate installation instructions
will be provided in the transport
packaging.
It is essential that you check the
components for possible damage
before installation.
You will receive separate instruc-
tions for assembling the system.
mail@graf.info
www.graf.info
instructions
Contents
1. SCOPE OF DELIVERY .................................................... 16
2. NOTES ............................................................................. 18
2.1 Safety
2.2 Ventilation and bleeding
3. CONSTRUCTION AND FUNCTIONAL PRINCIPLE ....... 19
4. INSTALLATION OF THE SET-UP KIT ............................ 19
5. INSTALLATION OF CONTROL UNIT ONE2CLEAN/PP
CABINET INDOOR .......................................................... 24
6. INSTALLATION OF THE CONTROL UNIT IN THE
OUTDOOR CONTROL CABINET S ................................ 25
7. INSTALLATION OF THE CONTROL UNIT IN THE
OUTDOOR CABINET M .................................................. 26
8. TECHNICAL DATA .......................................................... 27
