SycoTec 4033 xC-C3 Gebrauchsanweisung Seite 57

5.7.3 Flow chart touch probe (TP)
ATTENTION
The touch probe function (TP) may only be operated when the motor spindle is at a complete standstill.
*Running at speed is helpful to remove any fluid residues in the interface between static and rotating components.
*Running at speed is also a appropriate counter measure if a faulty connection between static and rotation component
is detected.
5.8 Connectors
Please refer to the specific data sheet for the connector type used in each case.
A detailed data sheet is available for each connecting cable and can be downloaded from www.sycotec.eu.
915
915-7P
MFJ
MFJ-5P
SycoTec recommends using the connecting cables listed in the accessories. If the connecting cable is to be manufactured
by yourself, please observe the assignment according to the above tables and contact your SycoTec contact person if
anything is unclear.
Name
Phase U
Phase V
Phase W
Protective conductor PE
Temperature sensor TP-
Temperature sensor TP+
Name
Phase U
Phase V
Phase W
Protective conductor PE
Temperature sensor TP-
Temperature sensor TP+
Touch probe (TP)
Name
Phase U
Phase V
Phase W
Protective conductor PE
Temperature sensor TP-
Temperature sensor TP+
Name
Phase U
Phase V
Phase W
Protective conductor PE
Touch probe (TP)
Not connected
Connector
A
B
C
1
2
Connector
A
B
C
1
2
3
Connector
1
2
3
4
5
6
Connector
1
2
3
4
5
6
Cable
U / 1
V / 2
W / 3
White
Black
Cable
U / 1
V / 2
W / 3
5
6
7
Cable
U / 1
V / 2
W / 3
White
Black
Cable
U / 1
V / 2
W / 3
White
Black
