Technical description
The SycoTec motor spindle 4033 xc-C3 is built on a modular platform design. Several hundred different combinations of functions
are possible. For detailed information on the equipment of your motor spindle, please refer to the respective data sheet. This
operating manual includes descriptions of all spindle functions and options.
5.1
Overview platform design
Possible features:
Bearing
Motor
system
33-AC-01
1vs1 HS
33-AC-02
1vs1 LS
33-DC-02
33-DC-02-NT
33-DC-03
5.2
Basic configuration
Pneumatic tool change
Spindle type
Motor
Motor type
Speed [rpm]
Motor system
Frequency [Hz]
Voltage Ph-Ph [V]
Current [A]
Power [W]
Temperature sensor
Bearing arrangement
Type
Amount
Lubrication
Max. speed bearings [rpm]
Clamping
Tool change
system
system
Pneumatic
C3
4 – 4.5 bar
Pneumatic
C3-L40
5.5 – 6 bar
Electrical
24V/2A, A, R, Y
4033 AC-C3-100-07-xx-xx
3~Asynchronous (AC)
S1:12 A / max. 20 A – 5s
S1: 680 / max. 860
Ceramic ball bearings
Lifetime lubricated
Sealing
Connector
system
IP55 with
915
sealing air
IP55 without
MFJ
sealing air
OE (direct
cable exit)
33-AC-02
100,000
100 – 1,666
33
KTY/PTC600
1vs1 HS
2
105.000
Housing
Shaft length
length
6 / 4.5 mm
Short
15 / 13.5 mm
Long
18 / 16.5 mm
ETC
Cylindrical
4033 DC-C3-60-05-xx-xx
33-DC-02
60,000
3~Synchronous (PMSM) (DC)
100 – 1,000
32
S1: 10 A / max. 18 A – 5s
S1: 450 / max. 800
PTC
1vs1 LS
Ceramic ball bearings
2
Lifetime lubricated
90.000
Others
ESD
Touch probe
9 (EN)
