Pattern is
very light and Moving the spray gun (6) too fast.
blotchy.
Spluttering Air bubbles in the return hose
paint. (10).
Suction
Hose (11) not
sucking up
Lack of pressure.
water when
cleaning the
unit.
The pressure control dial (9) is
set too low.
Mesh filter handle (26), the spray
tip (5), or the suction hose mesh
filter (13) is clogged.
The paint
pattern is
The suction hose (11) is loose at
tailing.
the suction hose inlet port (15).
The spray tip (5) is worn.
The paint is too thick.
44 | GB
Adjust pressure control dial (9) or decrease movement of
spray gun (6).
Perform "priming the pump" steps.
Using the appropriate cleaning solution in place of material,
perform the "priming the pump" steps.
Increase the pressure control dial (9) to a higher setting.
Clean mesh filter handle (26), the spray tip (5), and the suc-
tion hose mesh filter (13).
Re-adjust the suction hose (11) to the suction hose inlet port
(15) and use a flat head screwdriver to tighten the screw on
the metal hose clamp suction hose inlet port (16).
Replace the spray tip (5).
Thin the paint according to the
manufacturer's instructions.
