Carel humiFog Handbuch Seite 61

TB - G0A
pCO (H)
P
pCO (H)
TB - BKUP
TB - ONOF
TB - RKEN
TB - FLUX
TABELLE DER SICHERUNGEN:
F1-F2 -> 1A F 5x20 600V
F3-F4 -> 4A F 5x20 600V
F5 -> 4A T 5x20 250V
F9 -> 16A T 10,3x38 500V
FORZA DI SERRAGGIO MORSETTI pCO5+
TORQUE FORCE TERMINALS pCO5+
(Pound Inches) = 0,5 min -> 0,6 max
TB - NC1
TB - NC2
TB - NC3
TB - NC4
TB - NC5
TB - NC6
61 "humiFog multizone - Pumpenstation " +0300066DE - rel. 1.2 - 10.12.2015
GER
TB - NO1
TB - NO2
TB - NO3
TB - NO4
TB - NO5
TB - NO6
TB - NOV
