Invacare Softform Active 2 Rx Gebrauchsanweisung Seite 13

Test / Compliance
Immunity test
Conducted RF
3 V150 kHz to 80 Mhz
IEC 61000-4-6
6 Vin ISM & amateur
radio bands
Radiated RF 10 V/m80 Mhz to 2,7
GHz
IEC 61000-4-3
385 MHz - 5785 MHz
test specifications for
immunity to RF
wireless
communication
equipment r efer to
table 9 of IEC 60601-1-
2
These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from
structures, objects and people.
10.4 EMC Test Specifications
IEC 60601-1-2 — Table 9
Test
Band
Frequency
(MHz)
(MHz)
385 380 - 390
450 430 - 470
710
745 704 - 787
788
810
870 800 - 960
930
1720
1845 1700 - 1990
1970
2450 2400 - 2570
5240
5500 5100 - 5800
5785
If necessary to achieve the immunity test level, the distance between the transmitting antenna and the Medical Electrical
Equipment or System may be reduced to 1 m. The 1 m test distance is permitted by IEC 61000-4-3.
a)
For some services, only the uplink frequencies are included.
b)
The carrier shall be modulated using a 50 % duty cycle square wave signal.
c)
As an alternative to FM modulation, the carrier may be pulse modulated using a 50 % duty cycle square wave signal at 18 Hz.
While it does not represent actual modulation, it would be worst case.
13
Electromagnetic environment – guidance
level
Field strengths from fixed transmitters, such as base stations for r adio
(cellular/cordless) telephones and land mobile radios, amateur r adio, AM and FM
radio broadcast and TV broadcast, cannot be predicted t heoretically with
accuracy. To assess the electromagnetic environment d ue to fixed RF
transmitters, an electromagnetic site survey should b e considered. If the
measured field strength in the location in which t his product is used exceeds the
applicable RF compliance level above, t his product should be observed to verify
normal operation. If abnormal p erformance is observed, additional measures may
be necessary, such a s reorienting or relocating this product.
Interference may o ccur in the vicinity of equipment marked with the following
symbol:
Portable and mobile RF communications e quipment should be used no closer
than 30 cm to any part of this p roduct including cables.
a)
TETRA 400
GMRS 460, FRS 460
LTE Band 13, 17
GSM 800/900, TETRA 800, iDEN 820, CDMA
850, LTE Band 5
GSM 1800; CDMA 1900; GSM 1900; DECT; L TE
Band 1, 3, 4, 25; UMTS
Bluetooth, WLAN, 802.11 b/g/n, RFID 2450,
LTE Band 7
WLAN 8 02.11 a/n
a)
Service
10 Electromagnetic Compatibility
Immunity test
b)
Modulation
Pulse modulation
b)
18 Hz
c)
FM ± 5 kHz
deviation1 kHz sine
Pulse modulation
b)
217 Hz
b)
Pulse modulation
18 Hz
b)
Pulse modulation
217 Hz
b)
Pulse modulation
217 Hz
b)
Pulse m odulation
217 Hz
level (V/m)
27
28
9
28
28
28
9
