All installation and refitting work may only be carried out with the mains plug removed.
Your panel sizing saw is not completely assembled for packaging reasons.
1
2
3
Fastening the machine
Fasten the machine to the ground, especially if particularly large workpie-
ces will be processed.
•
1
Assembling the sliding table
•
•
•
•
•
•
Fit the washers onto the threaded pins and fasten the hexagonal nuts tightly.
Installing the protective hood
Parts required:
1.
2.
3.
4.
4
Fasten the machine to the ground. Holes are provided on all four feet (1) to
enable the machine to be bolted to the floor.
Assembling
Unpack the sliding table.
Remove the 4 hexagonal nuts and the 4 washers that are screwed onto the
4 threaded pins on the underside of the sliding table and set these to one
side carefully
Set the sliding table down carefully, ideally with two persons or with a
crane, on the machine frame such that the threaded pins feed through the
elongated holes of the frame.
Strike the threaded pins of the sliding table to work the sliding table into the
correct position.
The position of the two threaded pins is already set.
Protective cover
Coach bolt
Washer
Clamping lever
