ENVIRONMENT
The device is delivered in a package to protect it against any possible
transport damage. The packaging is made from non-processed
material and can be recycled. Throw the materials to appropriate
colour containers for selective waste collection.
Protect the environment and do not throw used batteries
into household wastes. Return them to the point of sale
or a special recycling centre.
Used electrical equipment (including the computer and
power supply) are recyclable. Do not throw them out with
household waste as they may contain substances dangerous to the
health and environment. You can actively contribute to sustainable
use of natural resources and the protection of the natural
environment by handing the used device to a recycling centre for used
electrical devices.
ASSEMBLY
The device must be assembled carefully by an adult. In case of doubt,
ask a more experienced person for help.
Prior to the assembly, make sure the set contains all
the listed elements and whether none of the parts was
damaged during transport. If any parts are missing or you have
any other reservations, contact the seller.
Have a look at the drawings and explanations and follow the
assembly manual when assembling the device.
Be careful during the assembly. There is a risk of injury when
using the tools and parts.
Remember to keep your surroundings safe. Do not let tools
and parts lie around in chaos. Remember that plastic foil and
bags pose o suffocation risk to small children.
Assembly parts necessary for a specific step in
the assembly manual are shown in pictures and included in
instructions. Use the elements indicated in the assembly
manual.
Do not tighten parts completely during the first stages
of the assembly. Tighten connections after all parts are placed
and fitted properly.
The manufacturer may have assembled some parts.
ASSEMBLY DIAGRAM (→ See page 2)
ATTENTION! Do not use parts other than those provided by the
manufacturer.
PARTS LIST
NO.
DESCRIPTION
1
Main frame
2 L/R
Treadmill column
3
Panel frame
4
Mobile device shelf
5
Front roller
6
Rear roller
7
Spring
8
Bushing Φ18*8
9
Running plate
10
Gear belt
11
Multi-groove belt
12
Upper panel cover
13
Lower panel cover
14
Foam handrail holder left
15
Foam handrail holder right
16
Upper motor cover
17
Lower motor cover
18
Left column cover (inner)
19
Left column cover (external)
20
Right column cover (inner)
21
Right column cover (external)
22
Column knob
23
Side running belt cover
24
Rear running belt cover
25
Transport wheel
26
Stabilizing feet
27
Shock absorber 1
28
Shock absorber 2
29
Screw M8*15
30
ST4.2*12 screw
31
Bumper 69*42*42
32
Pulse sensor
33
Pulse sensor
34
Control board
35
Safety key
36
Motor
37
Switch
38
Power cord 1.8m
39
Socket
40
Key S6 80X80
41
Power cable
42
Grounding
43
Screw M8*50 S6
44
Screw ST4.2*16
45
Screw ST4.0*30
46
Screw ST4.2*16
47
Screw M8*25 S6
48
Screw ST4.2*16
49
Screw ST4.2*25
50
Screw M6*35 S4
51
Screw M6*25 S4
52
Screw M8*40 S6
53
Screw ST2.9*12
54
Screw M8*12 S6
55
Washer Φ9* Φ16*t1.5
56
Spring washer D8
57
Washer Φ 5.2* Φ 10*t1
58
Screw ST3.5*10
59
Anti-slip nut M8 S13
60
Flat washer Φ10.5* Φ20*t2.0
61
Bottom wire
62
Side straps
63
Handle cover (left)
64
Handle cover (right)
65 L/R
Column cover
ASSEMBLY MANUAL (→ See page 3)
CAUTION! Follow the steps below during the assembly and use tools
supplied with the product. Prepare sufficient space for the assembly
operation. It is advisable to assemble the product with another person
because of the weight of some elements.
QUANTITY
1
FOLDING AND UNFOLDING (→ See page 6)
1/1
FOLDING THE DEVICE
1
NOTE! Before you start folding, check if all the bolts are tight and
1
disconnect the power supply cable.
1
NOTE! Be careful with your hands and fingers when folding so that
1
they do not get crushed.
2
2
Fold the handles upright. Unscrew both column folding knobs by
turning counterclockwise to loosen the hinge. Fold the columns flat
1
along the running belt. Turn the knobs again to lock the columns.
1
1
UNFOLDING THE DEVICE
1
PLEASE NOTE! Ensure there are no third party or animals in the
1
immediate treadmill vicinity when its belt is lowered.
1
Loosen both knobs for folding the columns by turning
1
counterclockwise to loosen the hinge. Stand the columns upright.
1
Turn the knobs again to lock the columns. Unfold the handles.
1
1
ADJUSTMENTS
1
Levelling
1
Level the device by rotating the levelling feet in the rear base.
1
2
COMPUTER MANUAL
2
1
START/STOP
4
The device starts five seconds after pressing the START/STOP button.
2
4
EN
2
3
12
2
1
1
1
1
1
1
1
1
1
2
1
3
10
2
17
2
12
7
4
4
4
8
2
2
2
1
2
4
2
1
4
1
1
1
16
