probst HVZ-ECO Betriebsanleitung Seite 93

Setting instructions
the HVZ-ECO hydraulic setting pliers
Pliers & accessories
Version A
The stone layer is not
displaced.
Must be moved with pliers
200
mm
1200 mm + half brick = 1300 mm *
Stone layer already displaced
200
mm
1300 mm
Version B
The stone layer is not
displaced.
Must be attached with pliers.
200
800
mm
mm
800
mm
These setting instructions were created using the latest data. Specifications
and illustrations are subject to change without notice.
1200 mm
800
mm
