3.4 Survey and construction
7
8
1 Operating handle
2 Rotating head (360°)
3 Setting of set-down rollers
4 Machine-side gripper cheek
3.5 Technical data
The exact technical data (carrying capacity / working load limit (WLL), dead weight, etc.) are listed on the type plate.
51400034
1
2
5 Side tension
6 Gripping depth adjustment
7 Face side gripper cheek
8 Steel plates
