Release the key on the right-side clamp and fasten it on the left side clamp.
•
Slightly loosen the two "L" screws that secure the probe support "7".
•
Move the probe support "7" to the left or right, until the probe is inserted into
the slot that we previously made in the key.
•
In this position, fasten the probe support "7" by means of the two "L" screws.
•
Now you can unlock the X axis of the carriage, operating the handle "14"
L
L
7
5.1.2 CUTTING DEPTH ADJUSTMENT
•
Lock the rotation of the clamp on the right side, operating the handle "16".
•
Fasten the adjustment rods in the clamp.
•
Unlock the rotation of the handle "12", loosening the screw "M".
•
Activate the probe spring, acting on handle "15".
•
Move the carriage forward, so that the adjustment rods rest on the "T" probe
and the "C" cutter.
•
Operating the handle "12", move the probe forward or backward, until the
probe "T" is resting on the adjusting rod "VT", the "C" cutter lightly rubs the
adjustment rod "VC".
•
Re-tighten the "M" screw.
12
M
15
T
VT
5.1.3 LATERAL STOP ADJUSTMENT
•
The BIT carriage is supplied with the factory-set Lateral Stops, so it is NOT
necessary to adjust them again.
•
However, after replacing the Lateral Stops, the way to set them would be as
follows:
•
Support the right side of the Lateral Stop "N1", against the internal bushing
"C1"
•
In this position, tighten the "R" screw to fix the Lateral Stop "N1".
•
Attach a "long male" type key to the right-side clamp, so that the bit is butted
against the Lateral Stop "N1".
•
Lock the "X" axis of the carriage, operating the handle "14".
•
Execute a straight groove of approximately 8 mm. of depth.
16
C
VC
16
•
Loosen the screw "Q" that fixes the internal bushing "C2".
•
Release the key on the right-hand side clamp and attach it to the left side clamp,
so that the "T" probe is inserted into the slot that we have made in the key.
•
In this key position, support the left side of the lateral stop "N2", against the bit
of the key.
•
In this position of the Lateral Stop "N2", tighten the screw "R" to fix the Lateral Stop
"N2".
•
Move the inner bushing "C2", until it touches the right-side of the Lateral Stop "N2".
•
In this position of the internal bushing "C2", lock it by means of the "Q" screw.
•
Now you can unlock the X axis of the carriage, operating the handle "14"
N2
C2
T
Q
R
5.2 ENCRYPTION
5.2.1 ENCRYPTION OF THE MORTISE KEYS
Fasten the key in the clamp. Depending on the type of key we want to cut, the stop of
the key will be made in one of the following ways:
- Key with stop on the stem:
Stop against the left side of the clamp.
- SHORT key (male/female) (simple/double probe):
Stop of the right side of the bit against the side left of the Cutter and the Probe.
- LONG MALE key (simple/double probe):
Stop against the Lateral Stop.
- LONG FEMALE key (simple/double probe):
Stop against the Lateral Stop. Use counterpoints for female key.
N1
C1
R
