Operating instructions
GB
CHAPTER 2
CONTROLLER
FUNCTION
NOTE
IMPORTANT NOTE
MENU
Comfort controller KWL-BEC
2.0 Initial start-up via KWL-BEC (comfort controller)
The unit control parameters can be easily adjusted via the comfort controller KWL-BEC.
Operating information on menu structure:
„Change" or „Continue" can be selected by rotating the rotary encoder right/left. For example, if „Change"
is shown with a black background, the function can be selected by pushing the rotary encoder. The
settings can be adjusted by rotating and the entry is confirmed by pushing (push). Following successful
adjustment, push „Continue" to move to the next menu item.
Step 1:
You will automatically be asked for the controller address during the system start-up. If an address has
already be assigned, it will no longer be requested. If several controllers are connected to the KWL-
ventilation unit, it should be ensured that the addresses are unique (address range AD 1-8).
Once all comfort controllers have received an individual address, proceed to step 2. Once the
controller address(es) are entered, the controller will reboot.
Step 2:
The start-up assistant starts. IMPORTANT: The initial start-up should only be performed with a connected
controller.
Start-up routine
Language:
Date:
Time:
Time zone:
Difference to
GMT in hours
Language selection Page 1: „German", „English", „French", „ Italian"
(change to „Functional level 2" via „More" item)
Selection Page 2: „More" > Function not in use
Date is shown and can be changed by overwriting.
Time is shown and can be changed by overwriting.
Enter / change: Current time zone displays (standard for DE GMT +1 or in the
summer GMT +2. Can be changed by overwriting.
2
