EtherCAT-Dokumentation | TxPDO Mapping IFD2415
Ch01Intensity1 TxPDOMap OV1
:001
0x1A30
0x6010:001 Ch01Intensity1_OV00
Ch01Intensity1 TxPDOMap OV2
:001
0x1A31
0x6010:001 Ch01Intensity1_OV00 0x6010:002 Ch01Intensity1_OV01
Ch01Intensity1 TxPDOMap OV4
:001
0x1A32
0x6010:001 Ch01Intensity1_OV00 0x6010:002 Ch01Intensity1_OV01 0x6010:003 Ch01Intensity1_OV02 0x6010:004 Ch01Intensity1_OV03
Ch01Intensity1 TxPDOMap OV8
:001
0x1A33 0x6010:001 Ch01Intensity1_OV00 0x6010:002 Ch01Intensity1_OV01 0x6010:003 Ch01Intensity1_OV02 0x6010:004 Ch01Intensity1_OV03
:005
0x6010:005 Ch01Intensity1_OV04 0x6010:006 Ch01Intensity1_OV05 0x6010:007 Ch01Intensity1_OV06 0x6010:008 Ch01Intensity1_OV07
Abb. 102 Mapping für Intensität 1 von DIST1
Ch01Intensity2 TxPDOMap OV1
:001
0x1A40
0x6011:001 Ch01Intensity2_OV00
Ch01Intensity2 TxPDOMap OV2
:001
0x1A41
0x6011:001 Ch01Intensity2_OV00 0x6011:002 Ch01Intensity2_OV01
Ch01Intensity2 TxPDOMap OV4
:001
0x1A42
0x6011:001 Ch01Intensity2_OV00 0x6011:002 Ch01Intensity2_OV01 0x6011:003 Ch01Intensity2_OV02 0x6011:004 Ch01Intensity2_OV03
Ch01Intensity2 TxPDOMap OV8
:001
0x1A43 0x6011:001 Ch01Intensity2_OV00 0x6011:002 Ch01Intensity2_OV01 0x6011:003 Ch01Intensity2_OV02 0x6011:004 Ch01Intensity2_OV03
:005
0x6011:005 Ch01Intensity2_OV04 0x6011:006 Ch01Intensity2_OV05 0x6011:007 Ch01Intensity2_OV06 0x6011:008 Ch01Intensity2_OV07
Abb. 103 Mapping für Intensität 2 von DIST2
confocalDT IFD2410/2411/2415
:002
:002
:002
:006
:002
:002
:002
:006
:003
:003
:007
:003
:003
:007
:004
:004
:008
:004
:004
:008
