19. Press outer and inside ttings together, so that they both are ush against the door.
20. Insert the supplied screws through the inside tting drill holes from inside the door and fasten to the outer
tting spacer bolts by hand (about 5-7 Nm).
21. Check that the outer handle can turn easily; if it does not, there may be a problem with the mortise lock
or the handle may have been tted incorrectly. In case of doubt, disassemble components and start again
from Step 10.
22. Push inside handle onto the inner tube until it will go no further.
23. Tighten the inside handle hex screw rmly by hand (about 5-7 Nm).
24. Push cover over the inside handle.
25. Carefully push the inlay through the opening in the inside cover.
26. Push the cover onto the inside tting, so that it is ush with the door. The cover is not symmetrical; look
carefully at the marking.
27. Click the inlay carefully into the cover.
28. Push cover over the outer handle.
29. Carefully push the inlay through the opening in the outer cover.
30. Push the cover onto the outer tting, so that it is ush with the door. The cover is not symmetrical; look
carefully at the marking to ensure correct positioning. (diagram 6)
31. Click the inlay carefully into the cover.
OPTICAL (HYBRID) / AUDIBLE FEEDBACK SIGNAL.
2 short audible signals / (Smart Handle Hybrid: 2 short audible signals + LED flashes blue twice briefly)
•
before engaging and a short audible signal after disengaging: indicates normal activation.
Warning Level 1 - Low batteries: eight short audible signals before engaging. Batteries will soon be
•
empty. Replace batteries in the SmartHandle.
Warning Level 1 (Hybrid – transponder use) - Low batteries: eight short audible signals before engaging.
•
Batteries will soon be empty. Replace batteries in the SmartHandle.
Warning Level 1 (Hybrid – Smart Card use) - Low batteries: eight short audible signals + LED flashes red
•
briefly 8x before engaging: Batteries will soon be empty. Replace batteries in the SmartHandle.
Warning Level 2 - Extremely low batteries: Eight short audible signals for 30 seconds with a one-second
•
break between each signal = emergency battery warning: batteries are almost completely empty. Replace
the batteries in the SmartHandle IMMEDIATELY.
Warning Level 2 (Hybrid – transponder use) - Extremely low batteries: Eight short audible signals for
•
30 seconds with a one-second break between each signal = emergency battery warning: batteries are
almost completely empty. Replace the batteries in the SmartHandle IMMEDIATELY.
Warning Level 2 (Hybrid – SmartCard use) - Extremely low batteries: 30 seconds long --> 8 short audible
•
signals + LED flashing red twice briefly with one second pause between each one = emergency battery
warning: batteries are almost completely empty. Replace the batteries in the SmartHandle IMMEDIATELY.
Active: Once Warning Level 2 has been emitted for the first time, the door can be opened with a
•
transponder around 50 times. After reaching this number of opening operations or after about 4 weeks,
SmartHandle automatically switches to emergency battery storage mode. Once at this warning level,
SmartHandle is in what is known as storage mode (G1) or freeze mode (G2) and can now only be
activated using a SimonsVoss programming device or a G2 battery replacement transponder. Consult the
SmartHandle manual for more details.
Hybrid: Once Warning Level 2 has been emitted for the first time, the door can be opened with a
•
transponder or SmartCard around 200 times. After reaching this number of opening operations or after
about 2 weeks, SmartHandle Hybrid automatically switches to freeze mode. Once at this warning level,
SmartHandle can now only be activated using a SimonsVoss programming device or using a G2 battery
replacement transponder. Consult the SmartHandle manual for more detailed information.
Eight short audible signals after disengaging: indicates that the transponder battery is empty. Transponder
•
battery must be replaced.
