• If parts of the machine are damaged, do not use the machine.
• If parts are missing, do not operate the machine.
• If parts are damaged or missing, contact the service center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in compliance with local regulations.
For your personal safety, do not insert battery before the tool is assembled completely.
3

INSTALLATION

3.1

INSTALL THE SEAT

See figure 3
1. Place the seat assembly over the seat panel and align holes as shown.
2. Install the bolts, washers and nuts and tighten securely.
3. Attach the sleeves to the nuts.
4. Make sure it is securely seated.
5. Connect the seat plug to the machine.
3.2

INSTALL THE MULCH COVER

See figure 4
The mower is configured for side discharge when shipped. If mulching is desired:
1. Place the mulch cover on the tab on the mower housing.
2. Align the holes in the mulch cover and the holes in the mower housing.
3. Install and tighten the bolts, screws, fixation clamps and bearing ring as shown.
3.3

INSTALL THE STEERING CONTROL LEVER

See figure 5-6
The left and right steering levers should be adjusted so that they align with each other when in the neutral position.
NEVER install the steering levers in an asymmetrical operating height.
1. Lift one steering control lever to align the holes in the lever with the holes in the corresponding mounting pole.
2. Select the preferred steering-lever operating height. Insert the screw together with the washer into the hole.
3. Use the wrench (13*16 mm) to secure the steering lever.
4. Assemble the other steering control lever in the same way.
Do not install the steering control lever reversely.
