Spohn & Burkhardt VCS0 Betriebsanleitung Seite 83

Spare part Name/items supplied
Double contact element pink
with solder tags for VCS0
1x double contact element pink
5x CS082-1 solder connection
Top part of the knob G41
for interlocking VCS0
1x cap
1x switching knob
1x knob disk M11x1 1x rubber diaphragm 1x NS0 ES106 locking plate for nuts on
the
1x O-ring
Top part of the knob H-button
for VNS0 & VCS0
1x NS0 ES41D-02 knob G41 with screw for NS0 and ST1
1x NS0 ES2 drive bush
1x washer, perforated washer for knob G41
1x NS0 ES106 locking plate for nuts on the stick Ø 8 mm 1x nut
1x cap for horn button G41
1x horn button
Top part of the knob HD G41
for VNS0 & VCS0 with HD button for horn, sealed
1x top part of the knob HD button
1x NS0 ES41D-02 knob G41 with screw for NS0 and ST1
1x NS0 ES2 drive bush
1x washer, perforated washer for knob G41
1x NS0 ES106 locking plate for nuts on the stick Ø 8 mm 1x nut
Top part of the knob HDV G41
for VNS0 & VCS0 with HDV button for horn, sealed, recessed
1x NS0 ES41D-02 knob G41 with screw for NS0 and ST1
1x NS0 ES2 drive bush
1x washer, perforated washer for knob G41
1x NS0 ES106 locking plate for nuts on the stick Ø 8 mm 1x nut
1x NS0 ES90HDV-1 top part of the knob HDV button
Top part of the knob, complete
for VNS0 & VCS0
1x cap
1x nut
1x washer, perforated washer for knob G41
1x NS0 ES2 drive bush 1x NS0 ES41D-02 knob G41 with screw for NS0 and ST1
1x NS0 ES106 locking plate for nuts on the stick Ø 8 mm
Spohn + Burkhardt
stick Ø 8 mm 1x nut
No.
54469
47194
47194
47271
47193
47192
83
