4. Description

The joystick VCS0 is a robust joystick suitable for medium-duty applications.
The drive block, made of a tracking-resistant, heat and cold-resistant insulating material, acts as the car-
rier for all mechanical parts and also provides protection against touching electrically conductive parts.
An optional zero, horn or deadman's contact is integrated space-savingly into the drive block so it is
protected. Touch-proof double contact elements for maximum 250 V and 10 A engage with a shaped fit
and are further secured to the drive block.
Due to the special design, the replacement of the double contact elements and the cam disks is straight-
forward.
Various gate modules are available for mechanically limiting or guiding the direction of movement.
Standard and special circuits can be implemented by means of the use of up to four double contact
elements per axis.
Potentiometers and encoders can be attached with a shaped fit by means of the use of a simple plug-in
coupling or directly instead of a double contact element.
Along with numerous applications in the bespoke equipment sector, the joystick VCS0 is used in cranes,
control stands and in portable control consoles due to its low weight.

4.1. Type codes

Solder connection
Type
Plastic escutcheon 96x96 mm
Aluminum escutcheon 72x72 mm
Boot holder S/S0/S1/S3
Lever length 110 | 140 mm
Stop gate | Bespoke gate | Cross gate |
Bespoke stop gate | Slot gate
Drive
Layout (standard=U)
}
Return R
Friction brake B
Fittings in lever/knob
Figure 1. Joystick VCS0 – type codes

4.2. Variants

The modular system for the joystick VCS0 makes possible an optimal configuration for the specific us-
age and to meet the requirements of the operating organization.
For variants and possible combinations, see Appendix A. "Examples for variants and available fittings",
page 89.
For a bespoke configuration, contact
page 2).
56
96
72 AK
S SK
S0 KK
S1 11 SAK E
K VCS0 S3 14 SZK V
}
}
Spohn & Burkhardt GmbH & Co. KG
X
Y
N R
U B H 8P1. 9P1 + B55.PQ55
Attachments in transverse direction
Attachments in viewing direction
Switching in transverse direction
Switching in viewing direction
(for contact data see Imprint,
