Operation of the system
After confi rming with the
use the (+) key to carry out the individual
points of the E-test with the (+) key. The
following message appears on the dis-
play:
E-Test, functions
with + and - keys
ESC <-
If you press the (+) button once, the yel-
low LED on the housing lights up and the
solenoid valve Y3 in the system is swit-
ched on. The display shows the following
message appears on the display:
JUNGBRUNNEN
LED yellow / Y3
– on
66-10/11
ESC <-
If the (+) key is pressed again, the red
LED on the the red LED on the housing
lights up. The display shows the following
message is shown:
LED red – on
ESC <-
When the (+) button is pressed again the
green LED on the housing lights up and
at the same time the solenoid valve Y2 is
switched on. The display shows the fol-
lowing message appears:
LED green / Y2
– on
ESC <-
If you now press the (+) key once more,
you will reach Y1. With this programme,
the solenoid valve Y1 is switched on. The
OK key you can
indication on the display looks like this:
When the (+) button is pressed again, the
Y5 is pressed again, the Y5 programme
-> OK
is switched on. With the Y5 programme,
the solenoid valve Y5 solenoid valve is
switched on. The appears on the display:
If the (+) key is pressed a second time,
you go to the Y4 programme. It is used
to switch on the solenoid valve Y4 is
switched on. This is only required for the
Jungbrunnen 66- 11, since the reservoir
pressure tank is emptied when the is
emptied when the withdrawal tap is
open.
The display shows the following mes-
sage:
When you press the (+) key again again,
you go to the Y0 programme. With the
Y0 programme, the main valve is is swit-
ched on. The display shows:
Water is fl ushed through the system
– Jungbrunnen 66-10 / 66-11
Y1 – on
ESC <-
Y5 – on
ESC <-
Y4 – on
ESC <-
Y0 – on
ESC <-
