Operation and controls
There is no protection against spray water when using a USB cable
with the X-node.
Checking the battery status
The battery status can be checked as follows:
Tilt the X-node more than 30° without the USB cable inserted.
– Charged
The status LED remains lit green: Battery >= 40 %
– Sufficiently charged
The status LED remains lit yellow: Battery 10 % ... 39 %
– Charging recommended
The status LED remains lit red: Battery < 10 %
The device only has enough power for a few more days.
52
Checking the charging process
The progress of the charging process can be read from the status
LED when the X-node is positioned on its side:
– The status LED remains red for as long as the X-node is charging
(X-node is tilted > 30°).
– The status LED remains green as soon as the charging process is
completed and the rechargeable battery has been completely
charged.
