Operation and controls
5.5

Viewing the gas readings

Gas concentration, temperature, relative humidity and air pressure
are updated every second on the live page. The current settings can
be seen in the lower half of the screen (see figure).
Current LoRa status
Current gas concentration
Current temperature
Status LED settings:
Display pattern and interval
LoRa settings:
Connected network ID
5.6

Settings

5.6.1

Setting the status LED

What is the status LED?
The status LED provides the user with information about the various
states of the X-node, enabling them to react appropriately.
62
General settings
Battery status
Current air pressure
Current humidity
Alarm limits setting:
Pre-alarm and main alarm
Calibration:
Last span calibration
Firmware version installed
Switching off the status LED:
The status LED can be switched off completely.
