Fault Nding - Signode BXT3-13 Originalbetriebsanleitung

6.8
If certain faults occur the background lighting of the operating panel and the fault display (symbol +
code) illuminate, and an acoustic signal sounds.
If the error is still pending (is not reset automatically), acknowledge by removing / inserting the re-
chargeable battery.
Display / state
Operating panel does not
react +
Display remains dark.
E11, red display +
pulsating (long)
Symbol ashes
E20, red display +
pulsating (long)
Symbol ashes
Symbols & ashing
E24, red display +
pulsating (long)
Symbol ashes
E25, red display +
pulsating (long).
Symbols & ashing
E27 (E23), red display
+ pulsating (long)
Symbol ashes
E33, red display +
pulsating (long)
Symbol
E37, orange display +
pulsating (medium)
Symbol
E50/51 orange display +
pulsating (medium)
Symbol
E57 orange display +
pulsating (medium)
Tension force display
ashes.
E55/56 orange display +
pulsating (medium)
Symbols &
In the case of other faults / fault numbers not described here, please contact the service centre.
If the error cannot be recti ed by applying the measures described above, please contact the service
centre!
50 of 53
ENGLISH
Cause / fault
Button lock is switched on.
Battery faulty / fully discharged.
Battery not properly inserted.
Inserted battery not permitted
(wrong battery).
Battery too hot (> 60°).
Battery temperature too low.
Battery not properly inserted.
Wrong battery.
Battery not properly inserted.
Temperature sensor faulty.
Battery undervoltage limits
reached.
Battery empty
Electronics overtemperature
Controller too hot
Tool jams during welding pro-
cess, soiled welding mechanism
or foreign body in tool.
Aborting of welding or cooling
process.
Strap slipped or broken.
Aborting of tensioning process
(AUTO)
SIGNODE BXT3-13/16/19
Elimination
Switch off button lock: see Section
4.6.
Charge/replace battery.
Check whether battery is complete-
ly inserted and unlocking device
engaged.
Insert correct battery.
Allow battery to cool.
Charge battery, replace if neces-
sary.
At a higher battery temperature
it recovers by itself.
Insert battery properly.
Charge battery, replace if neces-
sary.
Insert battery properly.
Replace if necessary.
Charge battery, replace if neces-
sary.
Allow tool to cool.
Clean welding mechanism.
Repeat strapping.
Reinsert strap.
Check: Tension force, soiled strap,
right strap and state of tension
wheel / tooth plate.
Repeat tensioning (AUTO).
V 02.16
