Signode BXT3-13 Originalbetriebsanleitung Seite 45

5.3.3 BXT3-19: Change from 16 mm to 19 mm (
Required parts
Strap guide rear 19 mm (8)
Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 16 mm (8).
Remove side cover (5).
Remove counter-sunk screw Torx (2) and strap guide front 16 mm (1).
Remove counter-sunk screw Torx (4) and strap guide front 16 mm (3).
Remove cylinder screw Torx (10) and strap guide rear 16 mm (9).
Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 19 mm (8).
BXT3-19: Change from 19 mm to 16 mm (
Required parts
Strap guide front 16 mm (1)
Strap guide front 16 mm (3)
Strap guide rear 16 mm (9)
Strap guide rear 16 mm (8)
Counter-sunk screw Torx, M4x6 (2) (4)
Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 19 mm (8).
Remove side cover (5).
Fit strap guide front 16 mm (1) (secure counter-sunk screw with Loctite 222).
Fit strap guide front 16 mm (3) (secure counter-sunk screw with Loctite 222).
Fit strap guide rear 16 mm (9) (secure cylinder screw with Loctite 222).
Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 16 mm (8).
46 of 53
ENGLISH
/
5
8
/ /
3 5
4 8
SIGNODE BXT3-13/16/19
/
3
4
Order number
1832.041.021
Order number
1832.031.117
1832.031.067
1832.042.048
1832.041.022
1912.204.064
V 02.16
