Setting Strap Tension - Signode BXT3-13 Originalbetriebsanleitung

4.3

Setting strap tension

The set tension force is displayed continuously when the tool is ready for operation.
Press "Tension force" button (2).
– The set tension force ashes for 5 sec-
onds.
– The + (1) and – (3) buttons appear.
– Unused displays disappear.
Press the + (1) or – (3) button until the desired
tension force is displayed.
– The status indicator bar (4) shows the set
tension force in relation to the possible
maximum value.
Save: Press the "Tension force" button (2) or
wait for 5 seconds.
Switch between display in "N" or "lbs": Press the ashing "Tension force" button (2) for
two seconds.
Every time the button is pressed an acoustic signal con rms the action.
The tension force is displayed continuously when the tool is operational.
Setting soft tension (Section 4.4).
BXT3-13:
Standard:
Soft
BXT3-16:
Standard:
Soft
BXT3-19:
Standard:
Soft
(rounded values)
* N = Newton / lbs = pound-force per square inch
38 of 53
ENGLISH
1 2
N* 400 500
lbs* 90 110
N 150 225
lbs 33 50
1 2
N* 900 1100
lbs* 200 250
N 400 520
lbs 90 115
1 2
N* 1300 1700
lbs* 290 380
N 400 550
lbs 90 115
SIGNODE BXT3-13/16/19
3
3 4 5
600 700 800
135 155 180
300 375 450
67 85 100
3 4 5
1300 1500 1700
290 340 380
640 760 880
145 170 200
3 4 5
2100 2500 2900
470 560 650
700 850 1000
145 170 200
4
2 1
6 7 8
900 1000 1100
200 225 250
525 600 675
120 135 150
6 7 8
1900 2100 2300
430 470 520
1000 1120 1240
225 250 280
6 7 8
3300 3700 4100
740 830 920
1150 1300 1450
225 250 280
9
1200
270
750
165
9
2500
560
1500
340
9
4500
1000
1600
340
