4.2

Setting the operating mode

Press the "Operating mode" button (1).
– Unused displays disappear.
– The currently set operating mode ashes
for 5 seconds.
– + and – appear.
Press the + (2) or – (3) button until the desired
operating mode is displayed.
–
MAN / SEMI / AUTO
By pressing the "Operating mode" button (1)
again, or after waiting for a period of 5 sec-
onds, the set mode is saved.
Every operating mode can also be selected
for the "Soft tension" tension range (Section
4.4).
SEMI–Semi-automatic strapping
(standard/factory setting)
The tensioning button (Section 3.1) must be
pressed and held down until the set tension force
has been reached. The straps are then automat-
ically welded and the upper strap is cut off. It can
be welded manually at any time by pressing the welding button.
For similar packaged goods.
AUTO–Fully automatic strapping
The tensioning button (Section 3.1) must only
be brie y pressed (touched). This triggers the
tensioning process. Once the set tension force
has been reached, the straps are automatically
welded and the upper strap is cut off.
For large quantities of identical packaged goods.
Depending on the application, the tool does not have to be held in the hand during the automatic
process. The next strapping can be already prepared.
WARNING
For an emergency stop in the case of danger (trapped person):
To release the strap tension (before welding), press the tensioning or welding button or
actuate the rocker lever.
After welding, break the strap at the welded seal or cut it using a tool.
MAN–Manual
The tensioning button (Section 3.1) must be
pressed and held down until the desired strap
tension has been reached. The welding button
(Section 3.1) must then be brie y pressed so that
the straps are welded and the upper strap is cut
off.
For dissimilar (soft, hard) packaged goods.
