Signode BXT3-13 Originalbetriebsanleitung Seite 44

Fit strap guide rear 9 mm (9) (secure cylinder screw with Loctite 222).
Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 9 mm (8).
5.3.2 BXT3-16: Change from 13 mm to 16 mm (
Required parts
Strap guide rear 16 mm (8)
Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 13 mm (8).
Remove side cover (5).
Remove counter-sunk screw Torx (2) and strap guide front 13 mm (1).
Remove counter-sunk screw Torx (4) and strap guide front 13 mm (3).
Remove cylinder screw Torx (10) and strap guide rear 13 mm (9).
Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 16 mm (8).
BXT3-16: Change from 16 mm to 13 mm: (
Required parts
Strap guide front 13 mm (1)
Strap guide front 13 mm (3)
Strap guide rear 13 mm (9)
Strap guide rear 13 mm (8)
Counter-sunk screw Torx, M4x6 (2) (4)
Remove battery from tool. Remove three cylinder screws Torx (6). Lift rocker lever towards the
handle, remove cylinder screw Torx (7) and strap guide rear 16 mm (8).
Remove side cover (5).
Fit strap guide front 13 mm (1) (secure counter-sunk screw with Loctite 222).
Fit strap guide front 13 mm (3) (secure counter-sunk screw with Loctite 222).
Fit strap guide rear 13 mm (9) (secure cylinder screw with Loctite 222).
Fit side cover (5) (secure cylinder screw with Loctite 222). Install strap guide rear 13 mm (8).
V 02.16
/
1
2
/ /
5 1
8 2
SIGNODE BXT3-13/16/19
/
5
8
Order number
1832.041.018
Order number
1832.031.116
1832.031.051
1832.042.043
1832.041.019
1912.204.064
