4

Preparing for operation and settings

4.1

Battery

For detailed information, see the separately enclosed operating instructions for the battery and the
charger.
4.1.1

Charging the battery

Connect charger to mains.
– Green LED illuminates (charger ready for
use).
Insert battery in charger.
– Green light ashes: Battery is being
charged.
– Green LED illuminates continuously:
Battery is fully charged.
Charging time: Charging of empty battery: approx. 15–45 min.
Ideal battery temperature during charging process: 15-40 °C
Avoid battery temperatures below 0 °C and over + 40 °C during the charging process.
The battery can be charged at any time, regardless of the charge status.
4.1.2

Inserting/removing battery in/from tool

Inserting the battery: Insert the charged battery into the tool. The unlock button must engage in the
second step (in the rst step the battery is held in place in the tool, but without electrical contact).
– The displays on the operating panel illuminate.
If the tool is not used for approx. ve minutes the display goes into sleep mode. Cancelling sleep
mode: Lift rocker lever.
If the tool is not used for a long period (days) the battery must be removed from the tool and
charged/stored in the battery charger.
Removing the battery: Press the unlock button and remove the battery at the same time.
4.1.3 Checking the charge status
LED display "Battery charge status" on oper-
ating panel, with battery inserted:
– The charge status is shown in % and by a
progress bar (1)
– 10% minimum charge (battery must be
charged)
– The information symbols (2) only appear if
a corresponding situation is pending (Section 6.7).
