After the display turns green and an acoustic
signal sounds the cooling time is ended. Lift
rocker lever.
– Rocker of the tensioning device opens.
Swivel the rear of the tool to the right away
from the strapping.
CAUTION
If the tool is removed too early the
display turns red and an acoustic sig-
nal sounds repeatedly (poor sealing
quality).
Carry out a visual sealing inspection (Section
5.2).
5.2

Checking the seal

WARNING
Never transport or move packaged goods with improperly performed strapping /
weld sealing - serious injuries may result.
Perform sealing check regularly.
Perform sealing check by visual inspection.
1 Good seal (the entire sealing area has been
cleanly welded, without excess material being
forced out sideways).
2 Poorly welded seal (weld not over entire
sealing area), welding time too short.
3 Poorly welded seal (excess material has
been forced out sideways), welding time too
long.
In the case of straps with poorly welded seals:
Check the welding time setting (Section 4.5).
Strapping with poorly welded seals must be performed again.
