32 O P E R A T I N G I N S T R U C T I O N S | PowerProx Mini - WTT4SLC
Information on the IO-Link functions can be found in the Technical information Photo‐
electric Sensors, SICK Smart Sensors/ IO-Link which is available for download from
www.sick.com (search for the device's part number).
Table 2: Process data structure (IO-Link version: V1.1 Process data length: 4 bytes)
No.
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bits 10...15
Bits 16...31
Table 3: Fault diagnosis
Display, error situation
Green LED flashes
Digital outputs not according
to graphic
Digital outputs not according
to graphic
Yellow LEDs flash at the same
time
Yellow LED flashes (only
briefly)
Yellow LED flashes fast, laser
is off, ISDU 36 shows "out
of specification" and one of
the events "Temperature too
high" / "Temperature too low"
is output.
Description
Byte 0: bits 31...24
Byte 1: bits 23...16
Byte 2: bits 15...8
Byte 3: bits 7...0
Q
L1
Q
L2
Qint.1
Qint.2
Qint.3
Qint.4
Qint.5
Qint.6
Qint.7
Qint.8
Empty
Analog value
Cause
IO-Link communication
IO-Link communication
Parameter settings made
manually, which deviate from
the standard
The sensor is not ready for
operation. The sensor will be
in the warming-up phase at
low ambient temperatures.
The sensor will have shut
down at excessively high
ambient temperatures.
Teach-in mode
The device enters the no-oper‐
ate state as it is operated
outside the specification (too
high/low temperature).
Data type
Boolean
Boolean
Boolean
Boolean
Boolean
Boolean
Boolean
Boolean
Boolean
Boolean
-
UInt16
Measure
Initiate a factory reset. The digi‐
tal outputs are reset to factory
settings.
At low ambient temperatures,
wait until the sensor has
warmed up. Ensure the sensor
cools down at excessively high
ambient temperatures.
Check the teach-in mode
Operate the device only within
the specification.
