작동 개시 - SICK PowerProx Mini WTT4SLC Betriebsanleitung

UL 승인 지침
5.1
연결부 핀 배열
5.2
작동 개시
6
감지 범위 설정
6.1
8022570.1FBN/15.09.2022 | SICK
예고 없이 변경 가능
The device shall be supplied from an isolating transformer having a secondary
overcurrent protective device that complies with UL 248 to be installed in the field rated
either:
a) max 5 amps for voltages 0 ~ 20 V (0 ~ 28.3 V peak), or
b) 100 / Vp for voltages of 20 ~ 30 V (28.3 ~ 42.4 V peak).
Alternatively, they can be supplied from a Class 2 power supply.
UL Environmental Rating: Enclosure type 1
핀 배열 개요
표 1: 핀 배열
WTT4SLC -3X32xxAxx
1
2
3
4
Q1
감지 범위 설정
-3X22xxAxx
+ (L+)
MF
- (M)
Q /C
1
4 3
1 2
white background (90%)
Example:
Sensing range on black, 6%,
x = 800 mm, y = 60 mm
작 동 지 침 서 | PowerProx Mini - WTT4SLC
작동 지침서
-3X11xxAxx
1 = brn
2 = wht
3 = blu
4 = blk
0.14mm
2
AWG26
x y
119
